NovaStar MCTRL660 Pro

The NovaStar MCTRL660 Pro is a professional LED display controller designed for both rental and fixed installations, such as concerts, live events, security monitoring centers, and sports arenas. It supports resolutions up to 1920×1200 at 60Hz and offers advanced features to enhance image quality and system performance.

Key Features:

• Input Options:
  • 1× 3G-SDI input
  • 1× HDMI 1.4a input
  • 1× Single-Link DVI input


• Output:
  • 6× Gigabit Ethernet ports
  • 2× 10G optical ports


• Loop Outputs:
  • 1× 3G-SDI loop output
  • 1× HDMI 1.4a loop output
  • 1× DVI loop output


• Advanced Features:
  • Supports 10-bit and 12-bit color depths, providing a more detailed and realistic image.
  • Ultra-low latency with less than 1 ms delay, ensuring smooth synchronized display.
  • Image mirroring and rotation capabilities for creative and flexible stage designs.
  • Easily switch between various application presets.
  • Stable and secure operation with multi-layered protection methods, including one-button restore from backup, web control, and input monitoring.


• Control and Connectivity:
  • 1× Type-B USB control port for PC connection
  • 1× Type-A USB port for cascading multiple units (up to 8 devices)
  • 1× Ethernet port for network control
  • Genlock IN and LOOP connectors for synchronization

Physical Specifications:

• Dimensions: 482.6 mm × 356.0 mm × 50.1 mm
• Weight: Approximately 4.6 kg
• Power Supply: AC 100–240 V, 50/60 Hz
• Operating Temperature: -20°C to +60°C
• Humidity: 10% RH to 90% RH, non-condensing
